Chain actuator C40

TOPP offers a wide range of simple, functional systems for the automation of doors and windows, designed to simplify our daily movements. Our natural vocation is a constant search for the perfect balance between design, function, technology and creativity.

For more than 20 years we have been offering our engineering know-how as an outside workshop, and our attention has always been focused on product innovation. Every device is tested individually to maintain our commitment to quality materials of the highest quality.

Benefits of window automation include:

► To reach hardly accessible window

► To automatically ventilate rooms

► To control safely the windows in case of rain

► To easily operate multiple windows simultaneously

► It allows great opportunities to achieve innovative solutions

► It enhances energy saving according to green thinking

► It gives great solutions to the needs of disabled people

► It has a worthy cost/benefit ratio

Chain actuator C40

Thrust force 400 N, Adjustable stroke max.500 mm

PRODUCT DESCRIPTION

Electric C40 actuator with double link articulated chain, enclosed in a suitable casing, with different mounting accessories for top and bottom hung windows. Operation at 230V 50Hz or, as an alternative, at 24V DC. Maximum applicable load 400N. Fast hooking and unhooking system of the chain to the window. Max. stroke 500mm, end of stroke adjustable at 100, 150, 200, 250, 300, 350, 400 mm by an external knob located on both sides of the actuator. Electronic device with acoustic warning to signal erroneous installation to the user. Electronic traction control with speed reduction, during the last 100mm of closing action. High protection IP 55 rated. Upon request, a preset “S” version for the synchronous operation of two actuators on the same window is available. CE marked device.
